Lens Spherical Grinding Machine: GSP-60
CG & SG multi-task machine.
By automating full-axis NC control, not require manual adjustment for axis movement, shorten setup time, and correct the wear of grinding wheels. It is possible to polish at a level where interference fringes are visible.
Based on the principles of machining, it realizes machining accuracy, reduced variation, and shortened machining time.
Features
- Enables rough and finish machining of spherical surfaces in one-time chucking with two wheel spindles.
- Pellet process in post-process is unnecessary or can be reduced.
- With two processing stages, it is possible to perform CG & smoothing automatically on both sides of the lens with one.
- Achieve significant process-intensive to perform outer diameter centering and chamfering.
- High accuracy and high quality with full NC for all axes, easy to compensate and change setups.
- Improves yield rate by increasing accuracy for the thickness on one side and thickness.
